Folding Wing Rotary Mower-M
The M-Series wide-cut rotary mowers with folding wings and enhanced power output set new standards in mowing performance. Equipped with 20 cutting blades as standard, they are designed for heavy-duty use and provide the finest grass and shrub trimming. Thanks to power transmission using multiple gearboxes, each with friction clutch protection, the power is evenly distributed throughout the mower, ensuring excellent reliability and durability.
The high-performance mowing function allows you to clear large areas of vegetation as quickly as possible, while the compact width in the transport position enables safe and efficient transportation between work sites. There are 7 models to choose from, with surface treatment widths from 3.6 to 12.8 meters.
Download Message
Product Details
| “M” Series Folding Wing Rotary Mowers | ||||||||
| Model | М1203 | М1503 | М1803 | М2005 | М2205 | М2605 | М3005 | М4207 |
| Cutting width (mm) | 3600 | 4570 | 5500 | 6100 | 6500 | 7980 | 9300 | 12 800 |
| Overall width (mm) | 3880 | 4830 | 5800 | 6500 | 6700 | 8150 | 9600 | 13 250 |
| Overall length (mm) | 4500 | 5000 | 5300 | 6100 | 6100 | 5150 | 6000 | 7420 |
| Weight (kg) | 1591 | 2580 | 2631 | 2990 | 2990 | 3620 | 5620 | 8210 |
| Cutting height (mm) | 40-300 | 80-350 | 40-300 | 30-300 | 30-300 | 50-350 | 50-380 | 50-380 |
| Cutting capacity (mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| Divider Gearbox Rating（Kw） | 80 | 194 | 80 | 194 | 194 | 194 | 194 | 260 |
| Wing /center Gearbox（Kw） | 60 | 157 | 60 | 157 | 157 | 157 | 157 | 157 |
| Number of Long knife | 6 | 6 | 6 | 15 | 15 | 15 | 15 | 21 |
| Number of Fixed short knife | 3 | 3 | 3 | 5 | 5 | 5 | 5 | 7 |
| Number of rotors（pcs） | 3 | 3 | 3 | 5 | 5 | 5 | 5 | 7 |
| Number of wheels (pcs) | 4 | 6 | 6 | 8 | 8 | 8 | 8 | 8 |
| Required PTO speed（rpm） | 540 or 1000 | 540 or 1000 | 540 or 1000 | 540 or 1000 | 540 or 1000 | 540 or 1000 | 540 or 1000 | 540 or 1000 |
| Recommended tractor power (HP) | 60-70 | 65-85 | 75-90 | 100-120 | 100-120 | 120-140 | 200-240 | 250-260 |
