Products
Product Details
| lTEMS | FLGCH-105 | FLGCH-115 | FLGCH-125 | FLGCH-135 |
| DIMENSIONS
(L x W x H) |
1180*925*1035mm | 1280*925*1035mm | 1380*925*1035mm | 1480*925*1035mm |
| STRUCTURE WEIGHT | 260Kg | 275Kg | 287Kg | 302Kg |
| CUTTING WIDTH | 1.02m | 1.12m | 1.22m | 1.32m |
| Work efficiency | 3300-9000m2/h | 3700-9800m2/h | 4000-10600m2/h | 4300-11400m2/h |
| PTO tumning speed | 540r/min | 540r/min | 540r/min | 540r/min |
| PTO SPLlNE | 6*8*900mm | 6*8*900mm | 6*8*900mm | 6*8*900mm |
| Power required (HP) | 18-25HP | 18-25HP | 18-25HP | 20-30HP |
| lTEMS | EFGCH140 | EFGCH160 | EFGCH180 | EFGCH200 | EFGCH220 |
| 3-POINT LINKAGE | CAT. L | CAT. L | CAT. L or ll | CAT. L or ll | CAT. L or ll |
| PACKING STYLE(CM) | 160*79*85 | 175*79*85 | 195*79*85 | 215*79*85 | 235*90*85 |
| GW/NW(Kgs) | 320/340 | 360/385 | 395/425 | 420/450 | 460/495 |
| Cutting width(M) | 1.35 | 1.55 | 1.75 | 1.95 | 2.15 |
| Gearbox(HP) | 35 | 45 | 50 | 50 | 50 |
| Packing style | Steel Crate | Steel Crate | Steel Crate | Steel Crate | Steel Crate |
| PTO tumning speed | 540r/min | 540r/min | 540r/min | 540r/min | 540r/min |
| PTO SPLlNE | 6*8*900mm | 6*8*900mm | 6*8*900mm | 6*8*900mm | 6*8*900mm |
| Power required (HP) | 30-45 | 45-55 | 60–90 | 70-110 | 80-120 |
